100nm Endotoxin Free Gold NanoUrchins media thumbnails
100nm Gold NanoUrchins
100nm Endotoxin Free Gold NanoUrchins-2
100nm Endotoxin Free Gold NanoUrchins-3

100nm Endotoxin Free Gold NanoUrchins

SKU: UEF-100-20

$145.00

Shipping calculated at checkout

Size: 20ml
Optical Density: 1 OD

Composition: Citric acid stabilized Gold NanoUrchins

Core Size: 100nm

Absorption max: 670nm

Particles per ml: 3.84E+9

Endotoxin Levels: <0.5 EU/mL

Formulation: Supplied in 0.1mM phosphate buffered saline (PBS)

Intended use: Our extensively purified endotoxin free Gold NanoUrchins are ideal for sensitive applications requiring a minimal amount of contaminants, such as cellular toxicity studies, immunological studies, and aseptic assays. This product is well suited for conjugate development by passive adsorption of proteins and other ligands to the gold nanoparticle surface. The resulting conjugate can then be used in downstream applications.

Properties

Cytodiagnostics Gold NanoUrchins are unique spherical gold nanoparticles with spiky protrusions, which result in absorption of light in the far-red. They are made using a unique proprietary protocol resulting in pure, reactant free particles with excellent size distribution.

Our Gold NanoUrchins have a narrow size distribution (CV of less than 8%) and exceptional protein adsorption properties. In addition, low batch to batch variability (+/- 2nm) assures you as a customer always end up with a product within the specified size range ordered.

All of our batches go through stringent quality control prior to shipment to our customers using dynamic light scattering to guarantee size and monodispersity and lot specifications are supplied with each product. The endotoxin levels of all batches are validated by the Limulus amebocyte lysate (LAL) test and do not exceed 0.5 EU/mL.

Storage

Store product away from direct sunlight at 4-25°C. Lower temperature prolongs the shelf life of the product.

Do NOT freeze. Freezing causes irreversible aggregation of the Gold NanoUrchins.

When stored as specified the product is stable for at least six months.

Download: Gold NanoUrchin Product Brochure

100nm Gold NanoUrchins UV-VIS Spectrum

Diameter  Peak SPR Wavelength (nm) NPS/ml* Wt. Conc. (mg/ml)* Molar Ext. (M-1cm-1) Size Dispersity (+/-nm) Particle Volume (nm3) Surface Area (nm2) Surface/Volume Ratio Particle Mass (g) Molar Mass (g/mol) Molar Concentration*
100 670 3.84E+09 3.89E-02 1.57E+11 <8% 5.24E+05 3.14E+04 0.06 1.02E-14 6.11E+09 6.37E-12

* All concentrations as indicated at an optical density of 1 (OD=1, i.e. absorbance at peak SPR wavelength with a 1cm pathlength)
